Additional Pictures



The DCM-50A Platform with the TMS0972NL/ZA0348 single-chip calculator circuit from a TI-1250 manufactured in August 1977.
Close-up view of the TMS0972NL single-chip calculator circuit.

Close-up view of the DIS233G Light-Emitting-Diode (LED) display module.
