Texas Instruments TI-31 Solar (Japan)
| Date of introduction: | 1986 | Display technology: | LCD |
| New price: | Display size: | 8 (5 + 2) | |
| Size: | 5.4" x 2.8" x 0.45" | ||
| Weight: | 2.4 ounces | Serial No: | 169519 |
| Batteries: | n.a. | Date of manufacture: | mth 07 year 1986 |
| AC-Adapter: | Origin of manufacture: | Japan (T) | |
| Precision: | 11 | Integrated circuits: | Toshiba T6974S |
| Memories: | 1 | ||
| Program steps: | Courtesy of: | Stefan Klaes |
Only
few month after introduction of the original TI-31
engineers at Toshiba choosed smaller solar cells and the calculator was renamed
to TI-31 SOLAR.
The
electronics inside the TI-31 SOLAR uses still the Toshiba T6974S single-chip
calculator circuit discovered in the TI-30 SLR.
Later the production of the TI-31 SOLAR was
shifted to China.
If you have additions to the above article please email: joerg@datamath.org.
